Euromex CMEX-5 WiFi-4 camera

Sensor
4M/Sony IMX347(C) CMOS 1/1.8 inch

Pixels
2688 x 1512 pixels, 4.0 Mpix

Scan mode
Electronic rolling shutter

Pixel size
2.9 μm x 2.9 μm

Filter
RGB color filter and IR-cut off filter (380-650 nm)

Mount
C-mount

Max fps
Up to 30 frames per second*

ADC
12 bits

Sensitivity
921mV with 1/30 sec

Exposure
Automatic or manual, from 0.021- 1000 ms

White balance
Automatic/manual

Dynamic range
48 db

S/N max
44 db

Data interface LAN
30fps*@2688*1512 H264 encoded video and Jpeg image capture

Data interface USB
MJPEG/H264 real-time images, 30fps*@2688*1512

*Frame rates were determined at optimal conditions

Operation
-10 – 50° C, 30-80 % humidity

Storage temperature
-20 to 60° Celsius

Power supply
Micro USB DC 5V/1A adapter

Supplied with
0.5x objective with C-mount (DC.1355), 30 and 30, 5 mm to 23.2 mm adapters for stereomicroscopes, 76 x 24 mm calibration slide (1mm/100), USB charger and USB-2 cable, CDROM with ImageFocus Alpha software, Android .apk app. A Mac OS version is also supplied (with a few differences in features). A carton box

Compatibility
Windows 10 and higher (32 and 64 bit configurations), Android Pad and Phones, Mac PC, iPad or iPhone

Requirements
PC with Intel Core2 2.8 GHz or higher or equivalent. Minimum 4Gb RAM memory PC with WiFi enabled. Android 5.1 and above is supported, Android 10.0 and above is recommended

Product number
DC.5000-WiFi-4
